The VSCOM USB-COM+ is one Port RS-232 USB-to-Serial Adapter, with optional feature to supply power output of 5V, 200mA - upper case by sliding open for easy to supply DC 5V power, all are connected to one DB9 male connector. for the 5V 2000mA setting there is no need to open chassis to set operation modes as upper case can be sliding open.
Features:
- Adds one RS-232 serial port by connecting to a USB port
- One DB9 male connector
- Optional feature to supply power output of DC 5V through PIN-9 of DB9 male to the serial devices requiring power
- Optional feature to supply power output of 5V, 200mA - upper case by sliding open for easy to supply DC 5V power
- Installed as standard Windows COM port
- Full RS-232 modem control signals and hardware/software flow control
- RS-232 data signals: TxD, RxD, RTS, CTS, DSR, DTR, DCD, RI, GND
- RS-232 data signals with DC 5V: TxD, RxD, RTS, CTS, DSR, DTR, DCD, DC 5V, GND
- High speed serial port with the baud rate up to 921.6K bps
- Non-standard baudrates supported
- LEDs of Power, TxD and RxD for easy port monitoring and diagnostic
- Serial port protected with surge protection of 10KV
- Powered by USB port, no external power adapter required
- Easy plug and play installation and RS-232 device connection
- COM port number assigned can be changed to any COM port number required
- Works with USB 1.1 & 2.0 host port
- Supports Windows 7/8/10, Vista, 2003, XP, 2000 and Linux
- Chip Set - FTDI
Specifications:
- USB Bus
- Compliance: USB 1.1/2.0 compatible
- Speed: 12 Mbps, hi-speed USB
- FIFO: 128 byte transmit FIFO, 384 receive FIFO
- Serial Interface
- Port Type: RS-232
- Number of Ports: 1
- Connectors: DB9 male
- Serial Line Protection: ESD Protection: 10KV
- Serial Port Speed: Baud Rate: 300 bps to 921.6k bps
- Serial Communication Parameters
- Data Bits: 5, 6, 7, 8
- Stop Bits: 1, 1.5, 2
- Parity: None, Even, Odd, Space, Mark
- Flow Control: RTS/CTS, XON/XOFF
- Serial Signals
- RS-232: TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND, RI
- RS-232 with DC 5V: TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND, DC 5V
- Driver Support: Windows 7, Win 10, Vista, 2003, XP (WHQL certified) and 2000 Linux Kernel 2.4 and up built-in support
- Power Supply: Input: Bus-powered, No external power adapter required
- Mechanical: Chassis: Plastic, ABS
- Environmental
- Operating Temperature: 0 to 55 °C (32 to 131 °F)
- Operating Humidity: 5 to 95% RH
- Storage Temperature: -20 to 75 °C (-4 to 167 °F)
- Safety Approvals: EN55022 Class B, EN55024, EN61000-3-2, EN61000-3, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, IEC 61000-4-11. CISPR PUB. 22 and FCC Part 15 Class B.
1-Port RS-232 USB-to-Serial Adapter
Model: USB-COM+
