The VSCOM USB-4COMi-M CBL delivers four serial port (RS-232/RS-422/RS-485) from USB connection.
Serial ports on USB allow further use of existing devices, even when the computer doesn't offer serial ports.The high speed serial port with the 128 byte transmit FIFO & 384 byte receive FIFO allow high speed communication, even in heavy loaded systems. Unique features reduce the system load. The serial port also allows unusual speed settings up to 921Kb with support to non standard Baud rates. As well the ports are protected with surge protection of 10KV.
USB-4COMi-M CBL uses a small case due to the high-density DB37 kombi connector for the serial ports. Mounted even in narrow environment, it connects to serial devices via spider cable or a connection box.
Supported mode are: RS-232; Standard RS-232 Mode, RS-422; 4-wire with handshaking, RS-485; 4-wire full duplex, RS-485; 2-wire half duplex with echo, RS-485; 2-wire half duplex without echo.
Features:
- Adds four industrial RS-232, RS-422 or RS-485 serial ports by connecting to a USB port
- Compact size box can be mounted to DIN rail conveniently
- Extension spider cable with DB37 connector to 4 DB9 serial ports
- Installed as standard Windows COM port
- SECC metal chassis with DIN rail bracket
- Hardware/software flow control
- RS-232 data signals: DCD, RxD, TxD, DTR, GND, DSR, RTS, CTS
- RS-422 data signals: TxD-, TxD+, RxD+, RxD-, GND, RTS-, RTS+, CTS+, CTS-
- RS-485 4-wire data signals: TxD-, TxD+, RxD+, RxD-
- RS-485 2-wire data signals: Data-, Data+
- Automatic transmit and receive control for 2-wire RS-485 half-duplex mode
- Termination resistors and biasing resistors built on board
- Operation Modes: RS-232; Standard RS-232 Mode, RS-422; 4-wire with handshaking, RS-485; 4-wire full duplex, RS-485; 2-wire half duplex with echo, RS-485; 2-wire half duplex without echo
- High speed serial port with baud rates up to 921.6K bps
- 128 byte transmit FIFO & 384 byte receive FIFO
- Non-standard baud rates supported
- LEDs of Power, TxD and RxD for easy port monitoring and diagnostics
- Serial port protected with surge protection of 10KV
- Powered by USB port, no external power adapter required
- Easy plug and play installation and RS-232 device connection
- COM port number assigned can be changed to any COM port number required
- Works with USB 1.1 & 2.0 host port
- Supports Windows 7/8/10, Vista, 2003, XP, 2000 and Linux
- Chip Set - FTDI
Specifications:
- USB Bus
- Compliance: USB 1.1/2.0 compatible
- Speed: 480 Mbps, hi-speed USB
- FIFO: 128 byte transmit FIFO, 384 receive FIFO
- Serial Interface
- Port Type: RS-232/RS-422/RS-485 selectable
- Number of Ports: 4
- Connectors: DB9 male
- Extension cable: DB37-to-4 DB9 cable, 30cm , or DB37-to-4 DB25 cable,30cm
- Serial Line Protection
- ESD Protection: 10KV
- Serial Port Speed
- Baud Rate: 300 bps to 921.6k bps
- Serial Communication Parameters
- Data Bits: 5, 6, 7, 8
- Stop Bits: 1, 1.5, 2
- Parity: None, Even, Odd, Space, Mark
- Flow Control: RTS/CTS, XON/XOFF
- Serial Signals
- RS-232: TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND
- RS-422: TxD-(A), TxD+(B), RxD+(B), RxD-(A), GND, RTS-(A), RTS+(B), CTS+(B), CTS-(A)
- RS-485-4 wire: TxD-(A), TxD+(B), RxD+(B), RxD-(A), GND
- RS-485-2 wire: Data-(A), Data+(B), GND
- Driver Support: Windows 7/8/10, Vista, 2003, XP (WHQL certified) and 2000 Linux Kernel 2.4 and up built-in support
- Power Supply: Bus-powered, No external power adapter required
- Mechanical: SECC metal chassis with DIN rail bracket
- Environmental
- Operating Temperature: 0 to 55 °C (32 to 131 °F)
- Operating Humidity: 5 to 95% RH
- Storage Temperature: -20 to 75 °C (-4 to 167 °F)
- Safety Approvals: EN55022 Class B, EN55024, EN61000-3-2, EN61000-3, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, IEC 61000-4-11. CISPR PUB. 22 and FCC Part 15 Class B.
4-Port RS-232/422/485 USB-to-Serial Adapter, Compact Metal Case with Extension Cable, DIN rail
Model: USB2-4COMi-M-CBL
