The VSCOM USB-4COM-M delivers four serial ports from USB connection.
This USB Serial Adapter is designed to make serial port expansion quick and simple. Connecting to a USB port on your computer or USB hub, this USB Serial Adapter instantly adds serial communication ports to your system. By taking advantage of the USB bus, this USB Serial Adapter makes it easier than ever to add 4 serial ports and serial devices to your system with easy plug-and-play and hot plug features.
Plugging the USB Serial Adapter into the USB port, the adapter is automatically detected and installed. There is no IRQ & COM port conflicts, since the port doesn't require any additional IRQ, DMA or memory on the system. The RS-232 ports function as native Windows COM ports, and it is compatible with Windows serial communication applications. Each port is individually configurable.
This USB Serial Adapter provides instant connectivity to RS-232 communication devices for factory automation, multi-drop data collection devices, barcode readers, time clocks, scales, data entry terminals, ATMs and serial communications in harsh environments. This USB to Serial Adapter is suitable for remote access, retail and industrial applications, data collection and other applications requiring high speed RS-232 communication ports.
Features:
- Adds four industrial RS-232 serial ports by connecting to a USB port
- Installed as standard Windows COM port
- SECC metal chassis with DIN rail bracket
- Full RS-232 modem control signals and hardware/software flow control
- RS-232 data signals: TxD, RxD, RTS, CTS, DSR, DTR, DCD, RI, GND
- High speed serial port with the baud rate up to 921.6K bps
- 128 byte transmit FIFO & 384 byte receive FIFO
- Non-standard baud rates supported
- LEDs for Power, TxD and RxD for easy port monitoring and diagnostics
- Serial port protected with surge protection of 10KV
- Powered by USB port, no external power adapter required
- Easy plug and play installation and RS-232 device connection
- COM port number assigned can be changed to any COM port number required
- Works with USB 1.1 & 2.0 host port
- Supports Windows 8, Windows 7/8/10, Vista, 2003, XP, 2000 and Linux
- Chip Set - FTDI
Specifications:
- USB Bus
- Compliance: USB 1.1/2.0 compatible
- Speed: 480 Mbps, hi-speed USB
- FIFO: 128 byte transmit FIFO, 384 receive FIFO
- Serial Interface
- Port Type: RS-232
- Number of Ports: 4
- Connectors: DB9 male
- Serial Line Protection: ESD Protection - 10KV
- Serial Port Speed
- Baud Rate: 300 bps to 921.6k bps
- Serial Communication Parameters
- Data Bits: 5, 6, 7, 8
- Stop Bits: 1, 1.5, 2
- Parity: None, Even, Odd, Space, Mark
- Flow Control: RTS/CTS, XON/XOFF
- Serial Signals: RS-232: TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND
- Driver Support: Windows 7/8/10, Vista, 2003, XP (WHQL certified) and 2000 Linux Kernel 2.4 and up built-in support
- Power Supply - Bus-powered, No external power adapter required
- Mechanical: SECC metal chassis with DIN rail bracket
- Environmental
- Operating Temperature: 0 to 55 °C (32 to 131 °F)
- Operating Humidity: 5 to 95% RH
- Storage Temperature: -20 to 75 °C (-4 to 167 °F)
- Safety Approvals: EN55022 Class B, EN55024, EN61000-3-2, EN61000-3, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, IEC 61000-4-11. CISPR PUB. 22 and FCC Part 15 Class B.
4-Port RS-232 USB-to-Serial Adapter, Metal Case
Model: USB2-4COM-M
