Sensoray model 2453 is a compact IP video server that captures and compresses analog audio and NTSC/PAL video and sends the resulting streams over Ethernet. It can simultaneously produce two output streams with independent resolutions, frame rates, and bit rates, allowing it to be easily tailored to match network capabilities and application requirements. It provides a number of advanced features including deinterlacing with motion artifact removal, real-time text overlay, and image rotation and mirroring.

Features:

• Two independent output streams from one video input
• H.264 HP@L3, MPEG-4 ASP, MJPEG video compression
• Supports MPEG-TS, H.264 VES, MJPEG over HTTP
• Streams via HTTP, RTP, RTSP, UDP
• G.711 or AAC-LC audio
• Includes RS-232/422/485 port and two GPIOs

Specifications:

• Video & Audio
• A/V Inputs
• video: NTSC/PAL composite, 75 Ω
• audio: line stereo, microphone mono.
• A/V Outputs
• video: NTSC/PAL composite, 75 Ω (decoder or pass-through mode)
• audio: line stereo.
• Video compression H.264 (HP@L3), Motion JPEG
• Audio compression
• G.711 (A-law, µ-law), 8 kHz, 8 bits/sample
• AAC-LC, 48 kHz, 32-512 kbps bitrate.
• Video capture resolutions
• 704x480, 352x240, 176x120 (NTSC)
• 640x480, 320x240, 160x120 (NTSC)
• 720x480, 360x240, 180x120 (NTSC)
• 704x576, 352x288, 176x144 (PAL)
• 720x576, 360x288, 180x144 (PAL)
• Frame Rate
• H.264: 30/15/10/6 fps (NTSC),
• 25/12.5/8.3/5 fps (PAL).
• Video streaming Up to 2 video streams with individually configurable compression types, bitrates, resolutions and frame rates.
• Output stream formats MPEG-TS, H.264 VES, MJPEG
• Image adjustments and processing
• Brightness, contrast, saturation, hue (NTSC)
• rotation (90°, 180°, 270°), mirroring
• interlacing artifacts removal
• text overlay with optional auto timestamps
• privacy mask.
• Network
• Network security Password protection; IP Address Filtering; Digest access authentication; User access log.
• Network protocols HTTP, RTP, RTSP, UDP
• Alarm triggers Video loss, GPI
• Alarm actions GPO activation, e-mail notification, HTTP, FTP upload.
• Other
• General purpose I/O
• 1 optically isolated or galvanically coupled input
• 1 optically isolated output
• (Requires optional 2453TA board).
• Serial interface RS-232/422/485
• Network interface 10/100Base-T(X)
• Power 1.7 W (typical), 2.2 W max, 5 V DC
• Operating temperature 0 to 70 °C
• Dimensions 3“ x 4.125“ (without enclosure)
• Mass
• 2453 (without enclosure): 74 g
• 2454: 17 g
• Options 2453TA termination board adds GPIO, USB host interface, real-time clock backup battery holder, SD card socket.

Part Numbers:

IP Video Encoder/Decoder Server

Model: 2453 Please see below
