Compliant with PCI-Experss Specification v2.0 and backward compatible with PCI-Express 4x
Compliant with Serial ATA Specification 3.1
PCI Express x4 interface, and compatible with PCI Express x8 and x16 slots.
Supports communication speeds of 6.0 Gbps, 3.0 Gbps, and 1.5 Gbps
Hot plug and Hot Swap.
Supports Native Command Queue (NCQ)
Supports AHCI 1.0 programming interface registers for the SATA controller
Supports aggressive power management
Supports error reporting, recovery and correction
Supports Message Signaled Interrupt (MSI)
Supports Programmable transmitter signal levels
Supports Gen 1i, Gen 1x, Gen 2i, Gen 2m, Gen 2x, and Gen 3i
Supports Port Multiplier FIS based switching or command based switching.
Supports Partial and Slumber Power Management states
Supports Staggered Spin-up
Compatible with SATA 6G, 3G and 1.5G Hard Drives.
Note: Not Supported RAID on PM
Supports Windows XP/Vista/7/8/8.1/10 Server 2003/2008 R2, Linux 2.6.x and above
