The VSCOM USB-4COMI-M delivers four serial ports (RS-422/RS-485) from USB connection in metal package.
Serial ports on USB allow further use of existing devices, even when the computer doesn't offer serial ports. The high speed serial port with the 128 byte FIFO allow high speed communication, even in heavy loaded systems. Unique features reduce the system load. The serial port also allows unusual speed settings like 500.000bps.
Features:
- Metal case
- DIN-Rail mountable
- 4 RS422/485 DB9 male ports
- Speed up to 921.6kbps
- No external power supply
- Chip Set - FTDI
Specifications:
- Speed: Up to 921.6kbps
- RS422/485 signals
- RS422 TxD+/-, RxD+/-, RTS+/-, CTS+/-, GND
- RS485 Data+/-, GND
- Ports: 4 RS422/485 ports
- Power: External power supply 5V DC required.
- Driver: Windows 98, ME, 2000, XP, 2003 Server and Vista, Win 7/8/10, Linux (Kernel 2.4 and up built-in)
- Connectors:4 DB9 male and terminal block
- Dimensions: 167 x 99 x 29 mm (W×L×H), 189 x 102 x 30 mm with DB9 connectors and ears
- Ordering information:
- Product Name: USB-4COMi-M
- Packing list: USB-4COMi-M, USB cable 0,9m, CD, English Documentation
- Optional Accessories: DK-35A DIN-Rail mounting kit
USB to 4 RS422/485 ports adapter
Model: USB-4COMI-M
