This VSCOM USB to 2 ports serial adapter is designed to make serial port expansion quick and simple. Connecting to a USB port on your computer or USB hub, this USB 2 ports serial adapter instantly adds 2 serial communication ports to your system with easy plug-and-play and hot-plug features.
Plugging the USB Serial Adapter into the USB port, the adapter is automatically detected and installed. There is no IRQ & COM port conflicts, since the ports don't require any additional IRQ, DMA or memory on the system. The RS-232 serial ports function as native Windows COM ports, and are compatible with OS serial communication applications. The operating system allows configure of each port individually.
This USB 2-port Serial Adapter provides instant connectivity to any two RS-232 communication device.
Features :
- Adds two RS-232 serial ports by connecting to a USB port
- Plugin converter connecting to a USB port conveniently
- Installed as standard Windows COM port
- Full RS-232 modem control signals and hardware/software flow control
- RS-232 data signals: TxD, RxD, RTS, CTS, DSR, DTR, DCD, RI, GND
- High speed serial port with the baud rate up to 921.6K bps
- Non-standard baudrates supported
- LED status indicators for TxD and RxD for easy port monitoring and diagnostic
- Serial port protected with surge protection of 10KV
- Powered by USB port, no external power adapter required
- Easy plug and play installation and RS-232 device connection
- COM port number assigned can be changed to any COM port number required
- Works with USB 1.1 & 2.0 host port
- Supports Windows 10, 8, 7, Vista, 2003, 2008, XP, 2000 and Linux
Specifications:
- USB Bus
- Compliance USB 1.0/1.1 compliant, USB 2.0 compatible
- Speed 12 Mbps, full-speed USB
- FIFO 128 byte transmit FIFO, 384 receive FIFO
- Serial Interface
- Port Type RS-232
- Number of Ports 2
- Connectors DB9 male
- Serial Line Protection - ESD Protection 10KV
- Serial Port Speed - Baud rate 300 bps to 921.6k bps
- Serial Communication Parameters
- Data Bits 5, 6, 7, 8
- Stop Bits 1, 1.5, 2
- Parity None, Even, Odd, Space, Mark
- Flow Control RTS/CTS, XON/XOFF
- Serial Signals - RS-232 TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND, RI
- Driver Support - Windows 10, 8, 7, Vista, 2008, 2003, XP (WHQL certified) and 2000, Linux Kernel 2.4 and up built-in support
- Power Supply - Input Bus-powered, No external power adapter required
- Mechanical - Chassis Plastic, ABS
- Environmental
- Operating Temperature 0 to 55 °C (32 to 131 °F)
- Operating Humidity 5 to 95% RH
- Storage Temperature -20 to 75 °C (-4 to 167 °F)
- Safety Approvals CE, FCC
USB to Dual Ports Serial RS-232 (DB-9) Adapter
Model: USB-2COM-PL
